A fun, lightweight 90mm EDF sport jet designed for precision aerobatics, completely 3D printed from LW-PLA and PETG.
The Xenon features multiple fast and secure snap connections on the wings and canopy. These allow for a quick and uncomplicated setup at the model airfield.
Specifications:
Wingspan: 1380 mm
Length: 1670 mm
Flying Weight: ~3.6 kg
Power Setup: 90 mm EDF, 90A ESC, 5300 mAh 6S LiPo
Build:
I used ColorFabb LW-PLA with 65% flow. The infill used is specified in the name of each respective part.
Minimum Printer size 250X250X250mm
We recommend a Freewing Landing gear with 50 mm tires on the main gear.
Center of Gravity (CG): 130 mm aft of the leading edge, measured at the wing break.
Materials needed:
2 m × 10 mm CFK tube, cut into 2 × 610 mm and 2 × 390 mm
4 m × 2 mm CFK rod for linkages and hinges
1 m × 5 mm CFK tube, cut into 2 × 200 mm for elevator reinforcement
2 × spools of ColorFabb LW-PLA
1 × spool of PETG
